REDUCING COUPLING
POLYETHYLENE PIPE ACCESSORY
POLYETHYLENE ACCESSORY
Range of accessories for the transport of high pressure water, irrigation, gaseous fuels, compressed air, chemical solutions and sludge.
Accessories can be adjusted using a metal wrench.
With more than 25 years of experience in product development in the sector.
Personalised advice
Our technical sales team will solve your doubts or needs.
Technical information:
*In the mobile version, swipe to the right to view the entire table.
REDUCING COUPLING | |||
MEASUREMENTS | UNIT. BOX | CODE | |
(mm) | (“) | ||
25 | 20 | 255 | 457160 |
32 | 25 | 150 | 457161 |
40 | 32 | 85 | 457162 |
50 | 40 | 60 | 457163 |
63 | 50 | 30 | 457164 |
75 | 63 | 18 | 457165 |
90 | 75 | 12 | 457166 |
110 | 90 | 8 | 457159 |
POLYETHYLENE ACCESSORIES MATERIALS
•BODY: PP-B polypropylene copolymer
•O-RING: NBR70 elastomeric rubber
• REINFORCING RING: EPDM elastomeric rubber for Zeeflex (pool hose fittings): stainless steel
• SPLIT RING: polyacetal
POLYETHYLENE ACCESSORY RANGE
Metric series PN16: from Ø16mm to Ø110mm
Metric series PN10: from Ø20mm to Ø63mm
Pressure adjustment bar PN16: Ø20mm – Ø25mm and Ø32mm
Zeeflex Pool Hose Series: Ø50 & Ø63mm
Rural series PN10 bar: from 3/4” to 2
PRESSURE RANGE POLYETHYLENE ACCESSORIES
12.5 bar at 20ºC for accessories from Ø75 to Ø110mm
