SAND FILTER
MANUAL SAND FILTERS
Manual sand filters are the most widely used filtration systems to filter water with a large amount of solids and organic material.
Available up to PN16.
With more than 25 years of experience in product development in the sector.
Personalised advice
Our technical sales team will solve your doubts or needs.
Technical information:
*In the mobile version, swipe to the right to view the entire table.
SAND FILTER | ||||
CONNECTION | DIAMETER | MAXIMUM FLOW | CAPACITY | CODE |
(“) | (mm) | (m³/h) | Kg Arena | |
1½" THREAD | 500 | 15 | 100 | 456671 |
2" THREAD | 700 | 25 | 200 | 461097 |
3" FLANGE | 800 | 35 | 300 | 456676 |
3" VITAULIC FLANGE | 950 | 50 | 500 | 458256 |
4" VITAULIC FLANGE | 1200 | 75 | 800 | 456670 |
SAND FILTERS CHARACTERISTICS
•The filter housing and collectors are made of carbon steel that undergoes a shot blasting-phosphating treatment and is electrostatically painted inside and outside in epoxy-polyester.
•They are equipped with collector arms that have a filling mouth at the top and a large one at the bottom for draining, enabling easy access to the inside of the filter.
•Maximum operating pressure: 10 kg/cm2
SAND FILTERING
SAND FILTER APPLICATIONS
•Water treatment
•Gardening
•Industry
